| 参数 | Specifications | 技术指标 Technique data | |||||||||
| 测量范围 | Measuring ranges | 0.75mH2O~600mH2O | |||||||||
| 过载压力 | Overload pressures | 150%F.S | |||||||||
| 破坏压力 | Burst pressures | 350%F.S | |||||||||
| 工作方式 | Operational Mode | 表压、绝压 | |||||||||
| 测量介质 | Measuring Media | 水、油 | |||||||||
| 输出信号 | Output signal | 25、50、100mV | |||||||||
| 工作电压 | Operating voltage | mV输出：10VDC(2.5~12VDc) mA输出：9~30VDc | |||||||||
| 综合精度 | Accuracy | ±0.1%F.S | |||||||||
| 长期稳定性 | Long-term drift | ≤±0.1%F.S/ year（typ.） | |||||||||
| 温度补偿范围 | Compensated temperature range | -2~+30℃ | |||||||||
| 工作温度范围 | Operating temperature range | -20~+60℃ | |||||||||
| 输出阻抗 | Output impedance | 2KΩ | |||||||||
| 绝缘阻抗 | Insulation resistance | ≥100MΩ(500VDC) | |||||||||
| 耐振性能 | Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| 耐冲击性 | Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| 抗干扰 | EMC proof | IEC 61000-6-2/3/4 | |||||||||
| 外壳材质 | Material | 钛 | |||||||||
| 防护等级 | Ip protection | IP68 | |||||||||
